FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
45 / 59
a) In the case of rough cutting
1. Rapid traverse up to the starting point.
2. Rapid traverse along the Z axis up to point R (END POINT Z + REMOVAL DEPTH +
CLEARANCE)
3. Descent along the lower Z axis in cutting feed (Z-CUT FEED RATE) by the pitch
(REMOVAL PITCH).
4. Cutting from the inside to the outside using the same cutting width (CUTTING WIDTH)
in cutting feed (FEED RATE).
5. After cutting, side finish allowance (SIDE FINISH) remains.
6. Rapid traverse along Z axis up to point R
7. Rapid traverse back to the starting point (A).
8. Rapid traverse down to the cutting surface + clearance (CLEARANCE) along Z axis.
9. Advance in –Z axis by the pitch (REMOVAL PITCH) and repeat steps 3. to 8. up to the
point of the distance (SIDE FINISH).
10. Rapid traverse along Z axis up to point R.
b) In the case of bottom finish cutting
1. Rapid traverse up to the starting point.
2. Rapid traverse along the Z axis up to point R (END POINT Z + REMOVAL DEPTH +
CLEARANCE)
3. Descent along the lower Z axis in cutting feed (Z-CUT FEED RATE) up to the end
point (END POINT Z).
4. Cutting from the inside to the outside using the same cutting width (CUTTING WIDTH)
in cutting feed (FEED RATE).
5. After cutting, side finish allowance (SIDE FINISH) remains.
6. Rapid traverse along Z axis up to point R
c) In the case of side finish cutting
1. Rapid traverse up to the starting point.
2. Rapid traverse along the Z axis up to the cutting point.
(Cutting point : It is calculated by END POINT Z, REMOVAL DEPTH, REMOVAL PITCH,
CLEARANCE)
3. Cut into the workpiece following a circular path.
4. Cutting of the side finish allowance (SIDE FINISH).
5. Move away from the workpiece following a circular path after cutting.
6. 3.-5. are repeated up to the point (END POINT Z) by the pitch (REMOVAL PITCH).
