Embedded macro for milling Supplement to Manual Page 59

Supplement to Manual
Apprv.Desig
.
Edit
Date
Design
Description
FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
59 / 59
4. Alarm
Number Message Contents
3001 INPUT VALUE IS
ERRONEOUS.
Necessary data is not entered. Or entered data
is invalid.
3002 OFFSET VALUE IS
UNDER 0.
The offset data corresponding to the specified D
code is 0 or less.
3003 INTERFREE WITH
WORK[RING]
The tool interferes with the opposite surface.
3004 TOOL IS TOO BIG.
Machining is impossible because the cutter
diameter is too large.
3005 APPROACH AMOUNT IS
BIG.
The tool interferes with the opposite edge because
the length of approach is too long.
3006 CORNER RADIUS[R] IS
BIG.
Corner R interferes with the opposite one because
the radius of corner R is too large.
3007 CHAMFER AMOUNT [R] IS
BIG.
Corner C interferes with the opposite one because
the chamfer amount is too large.
3008 DIA. IS BIGGER THAN R.
Corner R machining can not be performed because
the cutter diameter is larger than corner R
3012 CHAMF. TOOL EXCEDS
Z POINT
The chamfering tool interferes with the bottom
surface (Z point) in chamfering.
3013 CHAMF. TOOL ANGLE IS
LACK.
The angle at which the chamfering tool is placed is
not specified.
3022 D-CODE IS NOT CORRECT. D code is not specified.
3149 NO OPTION Option does not exist.
