FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
52 / 59
The following table shows addresses used in arguments in each machining process.
G232 T Z B J H D C D J H C F E X Y U R
Rough # # # # # # _ _ _ _ # # # # # # #
Bottom finish # # # _ # # _ _ _ _ # # # # # # #
Side finish # # # # # _ _ _ _ _ _ # # # # # #
Chamfer # # # _ _ _ # # # # _ # # # # # #
Drill # # # _ _ _ _ _ _ _ _ # _ # # # #
G232 S Q M W K A
Rough _ _ & & _ &
Bottom finish _ _ & & _ &
Side finish _ _ & & & &
Chamfer _ _ & & & &
Drill # # & _ _ &
# : Specify necessarily
& : Specify. If there is no input, default data is specified.
_ : Do not specify.
Movements :
Except for the shape of the track, the basic machining movements are similar to those of
Square pocket.
