Embedded macro for milling Supplement to Manual Page 58

Supplement to Manual
Apprv.Desig
.
Edit
Date
Design
Description
FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
58 / 59
3. Notes
(Note 1)This function requires the following optional functions.
# Embedded Macro
# Canned cycle
# Custom macro B
This function consists of 83 programs. So consider the number of programs which an
operator requires and specify one of the following optional functions.
# Number of Registered programs 125
# Number of Registered programs 200
# Number of Registered programs 400
# Number of Registered programs 1000
(Note 2)Common variables #400 - #436 are used by this function. (2)
(Note 3)Program numbers 9050 - 9650 are used by this function. (2)
(Note 4)The tape format for FS15 can not be used.
(Note 5)Specify D code before using G code program corresponding to Facing, Side cutting or
Pocketing after tool change.
(Note 6)In principle, specify arguments in order of description in this specification. Specially
concerning addresses I, J and K, specify in the following order. Firstly I, secondly J and
last K.
(Note 7)Plane selection (G17, G18 or G19) can not be specified. This feature can be used only
on X-Y plane.
(Note 8)It is necessary to specify decimal points to macro call arguments.
(Note 9)This function and MANUAL GUIDE can not be specified simultaneously. MANUAL
GUIDE has same functions as this function.
