FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
46 / 59
7. Rapid traverse along Z axis up to point R
(END POINT Z + REMOVAL DEPTH + CLEARANCE).
d) In the case of chamfering
1. Rapid traverse up to the starting point.
2. Rapid traverse along the Z axis up to the cutting point.
(Cutting point : It is calculated by END POINT Z, REMOVAL DEPTH, CHAMFER
REMOVAL, TOOL SMALL DIA., CHAMFER ANGLE, TOOL OUT DEPTH, CLEARANCE)
3. Cut into the workpiece following a circular path.
4. Cutting of the chamfering allowance (CHAMFER REMOVAL).
5. Move away from the workpiece following a circular path after cutting.
6. Rapid traverse along Z axis up to point R
(END POINT Z + REMOVAL DEPTH + CLEARANCE).
e) In the case of drilling for pre-hole
1. Rapid traverse up to the starting point.
2. Rapid traverse along the lower Z axis up to the point R.
3. Drilling along Z axis up to the point Z (END POINT Z).
4. Rapid traverse along Z axis up to point R level
(END POINT Z + REMOVAL DEPTH + CLEARANCE).
