Embedded macro for milling Supplement to Manual Page 57

Supplement to Manual
Apprv.Desig
.
Edit
Date
Design
Description
FANUC Series 16i/18i/21i-MA
Embedded macro for milling
A-77901E
Drawing No.
Title
2000.07.17
H.Minam
Date
2001.08.17
(2) is added.
Page
57 / 59
5. Widening of the groove on the right and left sides symmetrically using the cutting width
(CUTTING WIDTH).
6. The groove bottom side is cut leaving the side finish allowance (SIDE FINISH).
7. Rapid traverse along Z axis up to point R
c) In the case of side finish cutting
1. Rapid traverse up to the starting point (B).
2. Rapid traverse along the Z axis up to point R
(END POINT Z + REMOVAL DEPTH + CLEARANCE)
3. Move down along Z axis in cutting feed (Z-CUT FEED RATE) by the pitch (REMOVAL
PITCH).
4. Both sides groove are cut by the allowance (SIDE FINISH).
5. Move away from the workpiece after cutting.
6. 3.-5. are repeated up to the point (END POINT Z) by the pitch (REMOVAL PITCH).
7. Rapid traverse along Z axis up to point R
END POINT Z + REMOVAL DEPTH + CLEARANCE).
d) In the case of chamfering
1. Rapid traverse up to the starting point (B).
2. Rapid traverse along the Z axis up to the cutting point + CLEARANCE.
(Cutting point : It is calculated by END POINT Z, REMOVAL DEPTH, CHAMFER
REMOVAL, TOOL SMALL DIA., CHAMFER ANGLE, TOOL OUT DEPTH)
3. Move down along Z axis to the cutting point in cutting feed (Z-CUT FEED RATE).
4. Cut into the workpiece following a circular path.
5. Cutting of the chamfering allowance (CHAMFER REMOVAL).
6. Move away from the workpiece following a circular path after cutting.
7. Rapid traverse along Z axis up to point R
(END POINT Z + REMOVAL DEPTH + CLEARANCE).
