A. PARAMETERS
B–62443EN–2/03
148
Parameter 1601, bit 5 :
Disables in–position check during deceleration.
Parameter 1801, bit 4 :
Selects a parameter for in–position width between cutting
blocks.
Parameter 1826 :
In–position width
Parameter 1827 :
In–position width between cutting blocks
Parameter 3003, bit 0 :
Disables the interlock signal.
Parameter 3003, bit 2 :
Disables the interlock signal for each axis.
1) Common
Parameter 1300, bit 7 :
Selects whether an overtravel alarm is output before a limit
is reached.
2) Stored stroke limit 1
Parameter 1300, bit 2 :
Enables switching signal EXLM of stored stroke limit 1.
Parameter 1320 :
Positive coordinate I of stored stroke limit 1
Parameter 1321 :
Negative coordinate I of stored stroke limit 1
Parameter 1326 :
Positive coordinate II of stored stroke limit 1
Parameter 1327 :
Negative coordinate II of stored stroke limit 1
3) Stored stroke limit 2 (optional)
Parameter 1300, bit 0 :
Selects the stored stroke limit 2 prohibited area.
Parameter 1310, bit 0 :
Selects whether the stored stroke limit 2 check function is
supported (within the prohibited area).
Parameter 1322 :
Positive coordinate of stored stroke limit 2
Parameter 1323 :
Negative coordinate of stored stroke limit 2
4) Stored stroke limit 3 (optional)
Parameter 1310, bit 1 :
Selects whether the stored stroke limit check 3 function is
supported.
Parameter 1324 :
Positive coordinate of stored stroke limit 3
Parameter 1325 :
Negative coordinate of stored stroke limit 3
Parameters related to
in–position check
Parameters related to
interlock
Parameters related to
stroke limit
