LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 79

Connection manual
B–62443EN–2/03
3. CONNECTING THE LOADER CONTROL
BOARD OF THE Series 16i/18i/21i
79
Axis control function by PMC
1) Group A Axis control command signal
Axis control command read signal
Axis control command read finish signal
Reset signal
Axis control temporary stop signal
Servo off signal
Block stop signal
Block stop disable signal
Auxiliary function code signal
Auxiliary function strobe signal
Auxiliary function completion signal
Axis control feedrate signal
Axis control data signal
In–position signal
Following zero checking signal
Alarm signal
Axis moving signal
Auxiliary function executing signal
Negative–direction overtravel signal
Positive–direction overtravel signal
EC0A – EC6A <G143#0 – #6>
EBUFA <G142#7>
EBSYA <F130#7>
ECLRA <G142#6>
ESTPA <G142#5>
ESOFA <G142#4>
ESBKA <G142#3>
EMSBKA <G143#7>
EM11A – EM28A <F132>
EMFA <F131#0>
EFINA <G142#0>
EIF0A – EIF15A <G144 – G145>
EID0A – EID31A <G146 – G149>
EINPA <F130#0>
ECKZA <F130#1>
EIALA <F130#2>
EGENA <F130#4>
EDENA <F130#3>
EOTNA <F130#6>
EOTPA <F130#5>
2) Group B Axis control command signal
Axis control command read signal
Axis control command read finish signal
Reset signal
Axis control temporary stop signal
Servo off signal
Block stop signal
Block stop disable signal
Auxiliary function code signal
Auxiliary function strobe signal
Auxiliary function completion signal
Axis control feedrate signal
Axis control data signal
In–position signal
Following zero checking signal
Alarm signal
Axis moving signal
Auxiliary function executing signal
Negative–direction overtravel signal
Positive–direction overtravel signal
EC0B – EC6B <G155#0 – #6>
EBUFB <G154#7>
EBSYB <F133#7>
ECLRB <G154#6>
ESTPB <G154#5>
ESOFB <G154#4>
ESBKB <G154#3>
EMSBKB <G155#7>
EM11B – EM28B <F135>
EMFB <F134#0>
EFINB <G154#0>
EIF0B – EIF15B <G156 – G157>
EID0B – EID31B <G158 – G161>
EINPB <F133#0>
ECKZB <F133#1>
EIALB <F133#2>
EGENB <F133#4>
EDENB <F133#3>
EOTNB <F133#6>
EOTPB <F133#5>
3) Group C Axis control command signal
Axis control command read signal
Axis control command read finish signal
Reset signal
Axis control temporary stop signal
Servo off signal
Block stop signal
Block stop disable signal
Auxiliary function code signal
Auxiliary function strobe signal
Auxiliary function completion signal
Axis control feedrate signal
Axis control data signal
In–position signal
Following zero checking signal
Alarm signal
Axis moving signal
Auxiliary function executing signal
Negative–direction overtravel signal
Positive–direction overtravel signal
EC0C – EC6C <G167#0 – #6>
EBUFC <G166#7>
EBSYC <F136#7>
ECLRC <G166#6>
ESTPC <G166#5>
ESOFC <G166#4>
ESBKC <G166#3>
EMSBKC <G167#7>
EM11C – EM28C <F138>
EMFC <F137#0>
EFINC <G166#0>
EIF0C – EIF15C <G168 – G169>
EID0C – EID31C <G170 – G173>
EINPC <F136#0>
ECKZC <F136#1>
EIALC <F136#2>
EGENC <F136#4>
EDENC <F136#3>
EOTNC <F136#6>
EOTPC <F136#5>
