LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 16

Connection manual
1. OVERVIEW
B–62443EN–2/03
16
Item Specifications
Macro Macro executer (option 19)
Custom macro B (option 20)
Common variables addition (macro B)
(option 21)
Interruption type custom macro (option 22)
Editing Playback function (option 23)
Extended part program (option 24)
Language display English
Japanese (option 25)
Automatic operation If the NC issues an alarm, automatic operation is not
activated. Note, however, that automatic operation
of the NC is not affected by an alarm issued by the
loader.
Overtravel stroke limit Hardware OT (can be disabled by parameter set-
ting)
Stored stroke limit 1
Stored stroke limit 2 (option 26)
Stored stroke limit 3 (option 26)
(Only for T series)
Overtravel alarms (ALM 500 and 501) based on
stored stroke limit 1 are automatically released by
movement back along the axis to a point that does
not exceed the limit.
External key input External key input
External message/ Exter-
nal data input
External alarm message (option 27, 28)
External operator message (option 27, 28)
External program number search (option 28)
External workpiece coordinate system shift
(option 28)
External machine coordinate system shift
(option 28)
PMC axis control 4 path control (option 29)
Position switch Position switch function (option 30)
Multiple path waiting
function M code function
(Only for T series)
By specifying an M code from the NC and loader, a
wait operation can be performed.
Abnormal load detection Abnormal load detection function (option 31)
External deceleration External deceleration (option 32) ... For Series
16i/18i
