LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 61

Connection manual
B–62443EN–2/03
2. CONNECTION
61
Address table for Series 16/18/21 LCB
Bit No.
#7 #6 #5 #4 #3 #2 #1 #0Address
G0142 EBUFA ECLRA ESTPA ESOFA ESBKA EFINA
G0143 EMSBKA EC6A EC5A EC4A EC3A EC2A EC1A EC0A
G0144 EIF7A EIF6A EIF5A EIF4A EIF3A EIF2A EIF1A EIF0A
G0145 EIF15A EIF14A EIF13A EIF12A EIF11A EIF10A EIF9A EIF8A
G0146 EID7A EID6A EID5A EID4A EID3A EID2A EID1A EID0A
G0147 EID15A EID14A EID13A EID12A EID11A EID10A EID9A EID8A
G0148 EID23A EID22A EID21A EID20A EID19A EID18A EID17A EID16A
G0149 EID31A EID30A EID29A EID28A EID27A EID26A EID25A EID24A
G0150 DRNE RTE OVCE ROV2E ROV1E
G0151 *FV7E *FV6E *FV5E *FV4E *FV3E *FV2E *FV1E *FV0E
G0152
G0153
G0154 EBUFB ECLRB ESTPB ESOFB ESBKB EFINB
G0155 EMSBKB EC6B EC5B EC4B EC3B EC2B EC1B EC0B
G0156 EIF7B EIF6B EIF5B EIF4B EIF3B EIF2B EIF1B EIF0B
G0157 EIF15B EIF14B EIF13B EIF12B EIF11B EIF10B EIF9B EIF8B
G0158 EID7B EID6B EID5B EID4B EID3B EID2B EID1B EID0B
G0159 EID15B EID14B EID13B EID12B EID11B EID10B EID9B EID8B
G0160 EID23B EID22B EID21B EID20B EID19B EID18B EID17B EID16B
G0161 EID31B EID30B EID29B EID28B EID27B EID26B EID25B EID24B
G0162
G0163
G0164
G0165
