A. PARAMETERS
B–62443EN–2/03
152
Parameter 3404, bit 5 :
Selects specifications such that the beginning of a program
is not located by M02 in memory operation.
Parameter 3404, bit 7 :
Enables a multiple M code command.
Parameter 3411 :
M code 1 not to be buffered
Parameter 3412 :
M code 2 not to be buffered
Parameter 3413 :
M code 3 not to be buffered
Parameter 3414 :
M code 4 not to be buffered
Parameter 3415 :
M code 5 not to be buffered
Parameter 3416 :
M code 6 not to be buffered
Parameter 3417 :
M code 7 not to be buffered
Parameter 3418 :
M code 8 not to be buffered
Parameter 3419 :
M code 9 not to be buffered
Parameter 3420 :
M code 10 not to be buffered
Parameter 6200, bit 7 :
Enables dry run, overtravel, and automatic acceleration
/deceleration for a skip command.
1) Single block stop
Parameter 6000, bit 5 :
Enables a single block stop by a custom macro statement.
2) Macro variable
Parameter 3290, bit 2 :
Prohibits a macro variable from being input using the MDI
keys.
Parameter 6001, bit 6 :
Selects specifications such that a reset does not clear macro
variables 100 to 149.
Parameter 6001, bit 7 :
Selects specifications such that a reset does not clear macro
variables 1 to 33.
Parameter 6036 :
Number of custom macro variables shared by the loader and
NC (Variable numbers 100 to 149)
Parameter 6037 :
Number of custom macro variables shared by the loader and
NC (Variable numbers 500 to 531)
WARNING
The values of parameters 6036 and 6037 must agree with
the corresponding NC values. Otherwise, normal operation
cannot be performed.
Parameter related to skip
Parameters related to
macros
