1. OVERVIEW
17
NOTE
To use those functions for which option numbers are indicated, the following options are
required.
Option 1 Part program storage length 20m
Option 2 Part program storage length 40m
Option 3 Part program storage length 80m
Option 4 PMC Ladder 3000 step
Option 5 PMC Ladder 4500 step (For Series 16/18–MODEL A)
PMC Ladder 5000 step (For Series 16/18–MODEL B/C, Series 21–TB,
Series 16i/18i/21i)
Option 6 Reader Puncher control 1
Option 7 Directory display of floppy cassette
Option 8 Manual handle 1 unit control
Option 9 Manual handle 2 or 3 units control
(The use of the second and third units requires option 8 for the first unit.)
Option 10 Inch/metric conversion
Option 11 2nd feedrate override
(The Series 21, Series 21i does not support the 2nd feedrate override option.)
Option 12 Rapid traverse bell–shaped acceleration/deceleration
Option 13 Cutting feed linear acceleration/deceleration after interpolation
(For Series 16i/18i)
Option 14 3rd/4th reference position return
Option 15 Workpiece coordinate system
Option 16 Addition of optional block skip
Option 17 Stored pitch error compensation
Option 18 Programmable data input
Option 19 Macro executer
Option 20 Custom macro B
Option 21 Addition of custom macro common variables
Option 22 Interruption type custom macro
Option 23 Playback
Option 24 Extended part program editing
Option 25 Japanese display
Option 26 Extended stored stroke check
Option 27 External message
Option 28 External data input
(When the external data input option is selected, the external message option is
not required.)
Option 29 PMC axis control by PMC
Option 30 Position switch function
Option 31 Abnormal load detection function
Option 32 External deceleration (For Series 16i/18i)
