3. CONNECTING THE LOADER CONTROL
BOARD OF THE Series 16i/18i/21i
87
Address table for series 16/18/21 LCB
Bit No.
76543210
Address
G0170 EID7C EID6C EID5C EID4C EID3C EID2C EID1C EID0C
G0171 EID15C EID14C EID13C EID12C EID11C EID10C EID9C EID8C
G0172 EID23C EID22C EID21C EID20C EID19C EID18C EID17C EID16C
G0173 EID31C EID30C EID29C EID28C EID27C EID26C EID25C EID24C
G0174
G0175
G0176
G0177
G0178 EBUFD ECLRD ESTPD ESOFD ESBKD EFIND
G0179 EMSBKD EC6D EC5D EC4D EC3D EC2D EC1D EC0D
G0180 EIF7D EIF6D EIF5D EIF4D EIF3D EIF2D EIF1D EIF0D
G0181 EIF15D EIF14D EIF13D EIF12D EIF11D EIF10D EIF9D EIF8D
G0182 EID7D EID6D EID5D EID4D EID3D EID2D EID1D EID0D
G0183 EID15D EID14D EID13D EID12D EID11D EID10D EID9D EID8D
G0184 EID23D EID22D EID21D EID20D EID19D EID18D EID17D EID16D
G0185 EID31D EID30D EID29D EID28D EID27D EID26D EID25D EID24D
G0186
G0187
G0188
G0189
G0190
G0191
