LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 149

Connection manual
B–62443EN–2/03
A. PARAMETERS
149
Parameter 3111, bit 0 :
Enables the servo setting screen.
Parameter 1800, bit 1 :
Suppresses an alarm when VRDY is set to on before PRDY
is set to on.
Parameter 1820 :
CMR
Parameter 1821 :
Capacity of reference counter
Parameter 1825 :
Servo loop gain
Parameter 1850 :
Grid shift
Parameter 2000, bit 0 :
High–resolution bit
Parameter 2000, bit 1 :
Automatic servo parameter setting
Parameter 2001 :
AMR
Parameter 2020 :
Motor type
Parameter 2021 :
Load inertia ratio
Parameter 2022 :
Direction of motor revolution
Parameter 2023 :
Number of velocity detection feedback pulses
Parameter 2024 :
Number of position detection feedback pulses
Parameter 2084 :
DMR numerator for flexible feed gear
Parameter 2085 :
DMR denominator for flexible feed gear
NOTE
All other parameters numbered between 2000 to 2999 are
automatically set, being adjusted by the user only when
required.
Parameter 1815, bit 4 :
Determines the reference position.
Parameter 1815, bit 5 :
Selects an absolute pulse coder.
Parameter 1860 :
APC counter value at the reference position
Parameter 1861 :
APC counter value at the reference position (continued from
parameter 1860)
Parameters related to the
servo system
Parameters related to the
absolute pulse coder
