LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 89

Connection manual
B–62443EN–2/03
3. CONNECTING THE LOADER CONTROL
BOARD OF THE Series 16i/18i/21i
89
Address table for series 16/18/21 LCB
Bit No.
76543210
Address
F0000 OP SA STL SPL RWD
F0001 MA DEN BAL RST AL
F0002 MDRN CUT RPDO INCH
F0003 MTCHIN MEDT MMEM MMDI MJ MH MINC
F0004 MREF MAFL MSBK MABSM MMLK MBDT
F0005 MBDT9 MBDT8 MBDT7 MBDT6 MBDT5 MBDT4 MBDT3 MBDT2
F0006
F0007 SF MF
F0008 MF3 MF2
F0009
F0010 M07 M06 M05 M04 M03 M02 M01 M00
F0011 M15 M14 M13 M12 M11 M10 M09 M08
F0012 M23 M22 M21 M20 M19 M18 M17 M16
F0013 M31 M30 M29 M28 M27 M26 M25 M24
F0014 M207 M206 M205 M204 M203 M202 M201 M200
F0015 M215 M214 M213 M212 M211 M210 M209 M208
F0016 M307 M306 M305 M304 M303 M302 M301 M300
F0017 M315 M314 M313 M312 M311 M310 M309 M308
F0018
F0019
F0020
F0021
F0022 S07 S06 S05 S04 S03 S02 S01 S00
F0023 S15 S14 S13 S12 S11 S10 S09 S08
F0024 S23 S22 S21 S20 S19 S18 S17 S16
F0025 S31 S30 S29 S28 S27 S26 S25 S24
F0026
F0027
CNC³PMC
