B-62994EN/02 6. SETTING

-143-

6.5 Workpiece Origin Offset Settings

This section describes how to set the

Procedure

1. If the soft key is currently not displayed, press the function

selection key .

2. Press the soft key.

3. If the [Work Origin Offset] screen is currently not displayed, press the

chapter selection key .

Press the soft key.

The [Work Origin Offset] screen appears.

WARNING

Setting incorrect workpiece origin offset data may result in

unpredictable movement of the machine, resulting in damage to the

workpiece, the machine itself, or injury to the operator or bystanders.

Set workpiece origin offset data that is appropriate for the machining

program.

NOTE

To set workpiece origin offset data for the FS16/FS18/FS21, the

corresponding CNC option is required.

When the Power Mate is used, workpiece origin offset data cannot be

set.

To set the workpiece origin offset data, set the following status:

l Protect key

• Released

For an explanation of how to release the protect key, refer to the

manual provided by the machine tool builder.
