OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 187

Operators manual
B-62994EN/02 6. SETTING
-169-
6.8 Workpiece Coordinate System Shift Settings
This section describes how to set a workpiece coordinate system shift value.
Procedure
1. If the soft key is currently not displayed, press the function
selection key .
2. Press the soft key.
WARNING
Setting an incorrect workpiece coordinate system shift value may
result in unpredictable movement of the machine, resulting in damage
to the workpiece, the machine itself, or injury to the operator or
bystanders.
Set a workpiece coordinate system shift value that is appropriate for
the machining program.
NOTE
The workpiece coordinate system shift function is supported only by
FS16/18/160/180-TB/TTB/TC/TCC, FS21/210-TB, and
FS16i/18i/21i/160i/180i/210i-TA.
To set the workpiece coordinate system shift value, establish the
following status:
l Protect key
• Released
For an explanation of how to release the protect key, refer to the
manual supplied by the machine tool builder.
