B-62994EN/02 6. SETTING
-159-
6.6.4 Setting the life counter data included in the tool life management
data (for machining center systems)
The life counter data included in the tool life management data can be set.
Procedure
1. When the [Tool Life Management] screen is currently not displayed,
follow the procedure described in Section 6.6, "Tool Life Management
Data Settings" to display the [Tool Life Management] screen.
2. Choose the desired group from the list.
3. Press the soft key.
The [Tool Life Management - Life Counter] screen appears.
NOTE
The life counter data for a tool can be changed after the tool data has
been included in the tool life management data.
For an explanation of how to add a tool, see Section 6.6.1, "Adding a
tool to a tool group included in the tool life management data."
