PREFACE B-62994EN/02

p-4

7. SYSTEM

Explains how to display and set system-related information, and how to

input and output different types of data.

8. MESSAGES

Explains how to display alarms and other messages.

9. MILLING ANIMATION FUNCTION (OPTION)

Explains how to perform machining-in-progress drawing when a milling

machine tool is used.

10.CUSTOM

Explains how to insert an OLE object.

11.CUSTOMIZATION

Explains how to customize Basic Operation Package 1.

APPENDIX

Provides supplementary information to be read as required, such as how

to back up the setting file.

Notation Conventions

The following explains the notation conventions used in this manual:

lMenu, command, and screen notations

Example Explanation

[File] menu Menu names are enclosed in brackets [ ].

[Setting...] Command names are enclosed in brackets [ ].

[Program Edit] screen Screen names (displayed on the title bars) are

enclosed in brackets [ ].

<OK> button Command buttons on the display are enclosed

in angle brackets < >.

lKey notations and operation

Example Explanation

[Enter] key Key names are enclosed in brackets [ ].

[Ctrl]+[Tab] keys When keys are to be pressed and held down

sequentially, the keys are indicated by

connecting them with +, as shown on the left.

Direction keys The [→], [←], [↑], and [↓] keys are

collectively called the direction keys.
