9. MILLING ANIMATION FUNCTION (OPTION) B-62994EN/02

-302-

9.2 Performing Machining-in-Progress Drawing

This section explains how to make necessary settings including material data

setting and drawing scale setting for machining-in-progress drawing for a

running program. The section also explains how to start machining-in-

progress drawing.

Procedure

1. If the soft key is currently not displayed, press the function

selection key .

2. Press the soft key.

3. If the [Tool Data Edit] screen is currently not displayed, press the

chapter selection key .

Press the soft key.

The [Machining Draw] screen appears.

NOTE

l Machining-in-progress drawing is supported only by the

FS16i/18i/160i/180i-MA. In addition, a CNC option is required to

perform machining-in-progress drawing.

l Before machining-in-progress drawing can be performed, the tool

data for machining-in-progress drawing must be registered.

For an explanation of how to register tool data for machining-in-

progress drawing, see Section 9.1, "Setting Tools for Machining-in-

Progress Drawing."
