Series 15i/150i - Model B Parameter manual Page 143

Parameter manual
B-63790EN/01 4.DESCRIPTION OF PARAMETERS
- 133 -
1820 Command multiplier for each axis (CMR)
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
[Input type] Parameter input
[Data type] Integer axis
[Valid data range] See the following descriptions.
i) When CMR = 0.5 to 48
Set ACM (bit 7 of parameter No. 1816) to 0.
Then specify the value given by the following expression.
Setting = CMR*2
Valid range: 1 to 96
ii) When CMR = 1/2 to 1/27
(An optional command multiplier (option) is required)
Set ACM (bit 7 of parameter No. 1816) to 1.
Then specify the value given by the following expression.
Setting = 1/CMR
Valid range: 1 to 27
1821 Value of the numerator of a command multiplier for each axis (optional
command multiplier)
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
[Input type] Parameter input
[Data type] Integer axis
[Valid data range] 0 - 9999
Specify the value of the numerator of a command multiplier for each
axis. The optional command multiplier is required.
