B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 393 -

7635 Number of axes in a single block that can accept commands (remote buffer)

[Input type] Parameter input

[Data type] Integer

[Valid data range] 0 - Max axes

Set the number of axes in a single block that can accept commands

when using binary input operation mode. Do not change this

parameter during operation.

NOTE

The axes that can accept commands from the

remote buffer are the first n axes in the controlled

axis list, where n is the number of axes specified for

this parameter.

For example, when this parameter is 3, the fourth

and any subsequent axes in the controlled axis list

cannot accept commands.

7636 Number of a linear axis for which exponential interpolation is performed

[Input type] Parameter input

[Data type] Integer

[Valid data range] 1 - Max axes

Set the ordinal controlled axis number of a linear axis for which

exponential interpolation is performed.

7637 Number of a rotation axis for which exponential interpolation is performed

[Input type] Parameter input

[Data type] Integer

[Valid data range] 1 - Max axes

Set the ordinal controlled axis number of a rotation axis for which

exponential interpolation is performed.

7642 M code that causes switching to independent operation during twin table

control

[Input type] Parameter input

[Data type] Integer

[Valid data range] 1 - 999999999

Specify the M code that causes switching from synchronous or normal

operation to independent operation.

The M code specified for this parameter is handled as an M code

without buffering.
