Series 15i/150i - Model B Parameter manual Page 426

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63790EN/01
- 416 -
4.34 C LANGUAGE EXECUTOR PARAMETERS (DATA NO. 8649
AND LATER)
#7 #6 #5 #4 #3 #2 #1 #0
8650 INT PGU CKM EK
Y
CN
A
RS
K
[Input type] Parameter input
[Data type] Bit
NOTE
After this parameter has been set, the power must be
off turned off then back on for the setting to become
effective.
#0 RSK When the reset key is pressed, the key code is:
0: Not passed to the application.
1: Passed to the application.
#1 CNA If a CNC alarm is issued while a C language executor user screen is
being displayed:
0: Whether to automatically display the alarm screen depends on
the setting of bit 1 (NAP) of parameter No. 8000.
1: The alarm screen is displayed regardless of the setting of bit 1
(NAP) of parameter No. 8000.
#2 EKY The extended MDI keys are:
0: Not read.
1: Read.
#4 CKM The MDI key matrix is:
0: Not transferred to the CNC.
1: Transferred to the CNC.
Set this bit to 1 only when the CNC must directly read the key matrix.
In ordinary cases, set this bit to 0.
#5 PGU When a C language executor user screen is assigned to a program
screen:
0: The screen number common to the operation modes is used.
1: The screen number for each operation mode is used.
#6 INT The data block length (length) specified in a CNC function is checked,
assuming the size of int is:
0: 2 bytes.
1: 4 bytes.
