B-63790EN/01 4.DESCRIPTION OF PARAMETERS

- 57 -

1023 Servo axis number of each axis

NOTE

After this parameter has been set, the power must be

off turned off then back on for the setting to become

effective.

[Input type] Parameter input

[Data type] Integer axis

[Valid data range] 0 - Max axes

Specify the number of the servo axis that corresponds to each control

axis. Normally, set each servo and control axis to the same numbers.

The control axis number and servo axis number of an axis with an

absolute position detector must be the same.

- If FSSB setting mode is automatic setting mode (bit 0 of

parameter No. 1090 is set to 0), setting is made automatically by

inputting data to the FSSB setting screen. In manual setting

mode (bit 0 of parameter No. 1090 is set to 1), however, data

must be entered directly.

- The servo axes are associated with servo amplifiers by setting

parameter Nos. 1080 to 1089.

- For spindle motor axes such as the spindle positioning axis and

Cs contour control axis, 0 must be set.

- For axes under tandem control and electronic gear box (EGB)

control, a pair of two axes must be set. Set these axes as follows:

Tandem axis: Set 1, 3, 5, or 7 for the master axis. For the slave

axis to be used with the master axis, set a value

greater than the value set for the master axis by

one.

EGB axis: Set 1, 3, 5, or 7 for the slave axis. For the dummy

axis to be used with the slave axis, set a value

greater than the value set for the slave axis.
