Series 0i/0i Mate - Model B Connection manual (Function) Page 132

Connection manual (Function)
B–63833EN–1/02
2. PREPARATIONS FOR OPERATION
114
BFA When a command is issued where the resulting motion would exceed the
value of a stored stroke check 1, 3
0: An alarm is generated after the stroke check 1, 3 is exceeded.
1: An alarm is generated before the stroke check 1, 3 is exceeded.
#7
1301
#6 #5
OTF
#4 #3 #2 #1 #0
[Data type] Bit
OTF Defines whether to change the specification of the stored stroke check, as
follows:
0 : Not to change.
1 : To change as stated below.
S If the BFA (bit 7 of No. 1300) parameter is 1, stored stroke check
1 for a manual operation causes the axis to stop on the border and
an alarm to be issued.
S If the BFA (bit 7 of No. 1300) parameter is 1, stored stroke check
2 causes an alarm to be issued just before the stroke check is passed
through.
#7
1310
#6 #5 #4 #3 #2 #1
OT3x
#0
OT2x
[Data type] Bit axis
OT2x Defines whether stored stroke check 2 is checked for each axis is set.
0: Stored stroke check 2 is not checked.
1: Stored stroke check 2 is checked.
OT3x Defines whether stored stroke check 3 is checked for each axis is set.
0: Stored stroke check 3 is not checked.
1: Stored stroke check 3 is checked.
1322 Coordinate value of stored stroke check 2 in the positive direction on each axis
1323 Coordinate value of stored stroke check 2 in the negative direction on each axis
[Data type] Two–word axis
Increment system IS–A IS–B IS–C Unit
Metric input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
Rotation axis 0.01 0.001 0.0001 deg
[Valid data range] – 99999999 to 99999999
Defines the coordinate values of stored stroke checks 2 in the positive and
negative directions for each axis in the machine coordinate system. OUT,
#0 of parameter 1300, sets either the area outside or the area inside
specified by two checks as the inhibition area.
[Unit of data]
