Series 0i/0i Mate - Model B Connection manual (Function) Page 381

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

363

Name Description

Local coordinate system

(G52)

f *

Machine coordinate system

(G53)

f *

Workpiece coordinate system

(G54 to G59) (G54.1Pxx)

f *

Workpiece coordinate system

(G92)

f *

Workpiece coordinate system

preset (G92.1)

f *

Arbitrary angle chamfering/

corner rounding

Programmable data input

(G10)

f *

Only the tool offset value, workpiece origin

offset, and parameter can be modified.

Custom macro B f See the item of notes on using custom mac-

ros.

Custom macro common vari-

able addition

f *

Pattern data input

Interrupt–type custom macro

Canned cycle (G73 to G89)

f *

Initial level return (G98)/R

point level return (G99)

f *

Small–hole peck drilling cycle

(G83)

Arc radius R specification

Automatic corner override

(G62)

f Bit 0 (ACO) of parameter No. 7055 must be

set to 1.

Automatic corner decelera-

tion

Feedrate clamping based on

arc radius

Scaling (G51)

Coordinate system rotation

(G68)

Programmable mirror image

(G51.1)

F10/11 tape format
