Series 0i/0i Mate - Model B Connection manual (Function) Page 174

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

2. PREPARATIONS FOR OPERATION

156

(n is the value set in parameter No. 1891.)

[Classification] Output signal

[Function] Report the motor speed status of each of the axes controlled by spindle

motors.

[Operation] Each signal is set to 1 when:

· The spindle motor speed exceeds the maximum speed set in parameter

No. 4345.

Each signal is set to 0 when:

· The spindle motor speed does not exceed the maximum speed set in

parameter No. 4345.

CAUTION

1 Some of the servo motor speed detection signals DSV1 to

DSV4 and spindle motor speed detection signals DSP1 and

DSP2 may not function depending on the axis

configuration. Even when some signals do not function, the

addresses Y(n + 0) #3 to #0 and Y(n + 1) #1 and #0 must

not be used by the PMC ladder.

2 When this function is used, Y(n + 0) #7 to #2 are reserved.

These bits must not be used by the PMC ladder.

3 A spindle motor may be used for controlling a positioning

axis, or a servo motor may be used for a spindle. This

function performs motor–related detection.

Example: When Cs contour axis control is performed (the spindle and

C–axis are controlled by the first serial spindle motor), the

fourth axis is used as the C–axis.

In this case, if the preset maximum speed is exceeded, the

following occurs regardless of whether spindle control or

C–axis control is being performed:

DSP1 <Y(n + 1) #0, where n = setting in parameter No. 1891>

is turned on.

DSV4 <Y(n + 0) #3, where n = setting in parameter No. 1891>

is not affected.

Spindle motor speed

detection signals DSP1,

DSP2 <Y(n + 1)#0 to #1>
