12. DISPLAY/SET/EDIT

B–63833EN–1/02

734

6511

Right margin in solid drawing

6512

Left margin in solid drawing

6513

Upper margin in solid drawing

6514

Lower margin in solid drawing

[Data type] Word

[Unit of data] Dot

These parameters set the drawing margins in pixels on the screen. The

unit is a dot.

Standard set value

Parameter Margin

DPO=0 DPO=1

No. area

7.2″/8.4″

LCD

9.5″/10.4″

LCD

7.2″/8.4″

LCD

9.5″/10.4″

LCD

6511 Right 0 0 200 100

6512 Left 0 0 0 0

6513 Upper 25 32 25 32

6514 Lower 0 10 0 10

Set DPO with parameter No. 6500#5.

6515

Change in cross–section position in tri–plane drawing

[Data type] Byte

[Unit of data] Pixel

[Valid data range] 0 to 10

This parameter sets the change in the cross–section position when a soft

key is continuously pressed in tri–plane drawing. When zero is specified,

it is assumed to be 1.

NOTE

When the dynamic graphics function is used, the graphics

function cannot be used. (M series)
