Series 0i/0i Mate - Model B Connection manual (Function) Page 444
Connection manual (Function)
B–63833EN–1/02
9. SPINDLE SPEED FUNCTION
426
The table below lists the relationship between the spindles and functions.
f=Available ×=Unavailable
Serial spindle Analog spindle
Spindle
Function
First serial
spindle
Second serial
spindle
When used as the
first spindle (with
no serial SP)
When used as the
third spindle
(with a serial SP)
Thread cutting/feed per revolution
(synchronous feed)
f
f (*1)
f ×
Constant surface speed control
f
f (*1)
f ×
Spindle speed fluctuation detection
f
f (*1)
f ×
Actual spindle speed output
(T series)
f
f (*1)
f ×
Spindle positioning (T series)
f × f ×
Cs contour control
f × × ×
Multi–spindle (*2)
f
(First spindle)
f
(Second spindle)
×
f
(Third spindle)
Rigid tapping
f
f (*1)
f ×
Spindle synchronous control f Master f Slave
× ×
Spindle control unit functions, such
as spindle orientation, spindle out-
put switching, spindle switching, and
etc. (*3)
f f f f
Polygon turning (T series)
(using the servo motor axis and
spindle)
f
f (*1)
f ×
Spindle output control by the PMC
f f f f
NOTE
1 The multispindle function is necessary. The function cannot
be used for the first and second spindles simultaneously.
2 The multispindle function can control the speed of three
spindles and switch the feedback signal between two
position coders. It also can work without the second or third
spindle.
3 These functions belong to the spindle control unit. They
cannot be used unless the spindle control unit supports
those functions.
