Series 0i/0i Mate - Model B Connection manual (Function) Page 779

Connection manual (Function)
B–63833EN–1/02
12. DISPLAY/SET/EDIT
761
NOTE
1 The asterisk (*) is used as a control code, so it cannot be
used in the item name. Likewise, square brackets “[” and
“]” and parentheses “(” and “)” must be excluded from the
item name.
2 If a null item is selected on the machine maintenance
screen, the warning message “EDIT REJECTED” will
appear. If a null item name is selected on the NC
maintenance screen, a blank will be set up.
3 When a blank item is selected on a screen of the machine,
a warning “Unable to edit” is issued.
When a blank item is selected on a screen of the NC, a blank
is set.
To delete a registered item name, place the cursor on it, and press the
[CLEAR] soft key, then the [EXEC] soft key.
[Machine maintenance screen]
PERIODICAL MAINTENANCE O0001 N12345
(MACHINE)
ITEM NAME
01
02
03
04
05
06
07
08
09
10
>_
EDIT *** ***** *** **** 19:27:05
[ ][ STATUS ][ MACHIN ][ NC ][ (OPRT) ]
[ SELECT ][ ][ CLEAR ][ +INPUT ][ INPUT ]
[ ][ ][ ][ CAN ][ EXEC ]
[ ][ READ ][ PUNCH ][ ][ ]
[ ][ ][ ][ CAN ][ EXEC ]
