16. INTERFACE WITH THE POWER MATE CNC

B–63833EN–1/02

960

NOTE

1 The signals are valid when bit 5 (MP) of parameter No. 5 for

the b servo unit is set to 1.

2 The signals are valid only in the manual handle mode.

3 The signals are used also as rapid traverse override signals.

In the manual handle mode, the signals function as the

incremental feed signals. In modes other than the manual

handle mode, the signals function as the rapid traverse

override signals. When the mode is switched from the

manual handle mode to another mode, the setting of the

signals need to be returned to the setting of the rapid

traverse override signals.

Yy+0

#6 #5 #4 #3 #2

MD4

MD2

MD1

Yy+7

#6 #5

MP2

MP1

#3 #2 #1 #0

005

#6 #5

IOH

#3 #2 #1 #0

[Data type] Bit

IOH Manual handle feed via the I/O Link is:

0 : Disabled.

1 : Enabled.

CAUTION

When IOH is set to 1, be sure to set bit 6 (EXPLS) of

parameter No. 3 on the b servo unit side to 0.

MP In manual handle feed, four–stage magnification setting using the

MP1/MP2 signals for input manual handle pulses is:

0 : Disabled.

1 : Enabled.

Signal address

Parameter (on the b

servo unit side)
