Series 0i/0i Mate - Model B Connection manual (Function) Page 218

Connection manual (Function)

Page of 1090

/ 1090

4. REFERENCE POSITION ESTABLISHMENT

B–63833EN–1/02

200

The G30 command positions the tool to the 2nd, 3rd, or 4th reference

position, via the specified intermediate point. It then sets the completion

signal for 2nd, 3rd, or 4th reference position return to 1.

Before issuing the G30 command, The 2nd, 3rd, or 4th reference position

must be set in parameter No. 1241, 1242, or 1243 with coordinates in the

machine coordinate system.

The tool moves to the intermediate point or 2nd, 3rd, or 4th reference

position at the rapid traverse rate.

Return to the 2nd, 3rd, or 4th reference position can be performed only

after the reference position has been established.

[Classification] Output signal

[Function] The second, third, and fourth reference position end signals report the tool

is at the second, third, and fourth reference positions on a controlled axis.

These signals are provided for axes in a one–to –one correspondence. A

numeric character appended to the end of a signal represents a controlled

axis number, and a numeric character immediately following ZP

represents a reference position number.

4.5

2ND REFERENCE

POSITION

RETURN/3RD, 4TH

REFERENCE

POSITION RETURN

General

Signal

Second reference

position return end

signals ZP21 to ZP24

<F096>

Third reference position

return end signals ZP31

to ZP34 <F098>

Fourth reference

position return end

signals ZP41 to ZP44

<F100>
