10. TOOL FUNCTIONS
B–63833EN–1/02
620
#7 #6 #5 #4 #3 #2 #1 #0
6801
M6E
EXG
EXT
TSM
EMD LFV
[Data type] Bit
TSM When a tool takes several tool numbers, life is counted in tool life
management:
0 : For each of the same tool numbers.
1 : For each tool.
LFV Specifies whether life count override is enabled or disabled when the
extended tool life management function is used.
0 : Disabled
1 : Enabled
EMD An asterisk (*) indicating that a tool has been expired is displayed,
0 : When the next tool is selected
1 : When the tool life is expired
EXG Tool life management data registration by G10 (T series) is:
0 : Performed after the data for all tool groups has been cleared.
1 : Performed by adding/changing or deleting the data for a specified
group.
EXT Specifies whether the extended tool life management function is used.
0 : Not used
1 : Used
M6E When a T code is specified in the same block as M06
0 : The T code is processed as a return number or as a group number
selected next. Either is set by parameter M6T No. 6800#7.
1 : The tool group life is counted immediately.
#7
6803
#6 #5 #4 #3 #2 #1
LFE
LFE
#0
LGR
NOTE
After this parameter has been set, the power must be turned
off then on again for the setting to become effective.
[Data type] Bit
LGR When the tool life management function is used, a tool life type is:
0 : Chosen based on the LTM parameter (bit 2 of parameter No.6800) for
all groups.
1 : Set to either count or duration on a group–by–group basis.
When LGR is set to 1, the specification of address Q is added to the G10
(tool life management data setting) command format. As shown in the
example below, specify the tool life of each group as either a count or a
duration. If address Q is omitted for a group, the specification of the LTM
parameter (bit 2 of parameter No.6800) applies to the group.
