B–63833EN–1/02

9. SPINDLE SPEED FUNCTION

570

5203

#6 #5 #4

OVS

RGS

RFF

#1 #0

[Data type] Bit

REF Feed forward during movement from the initial point to point R in rigid

tapping is:

0 : Disabled.

1 : Enabled.

When this parameter is set, the following function is also enabled:

D When rigid tapping is specified in advanced preview control mode, the

system automatically exits from advanced preview control mode and

executes rigid tapping. After termination of rigid tapping, the system

automatically returns to advanced preview control mode.

RGS When bit 0 (MIF) of parameter No. 1403 is set to 1 and rigid tapping is

specified in feed–per–minute mode, the spindle speed becomes:

0 : 1/1000 of the specified speed.

1 : 1/1 of the specified speed.

OVS In rigid tapping, override by the feedrate override signal and invalidation

of override by the override cancel signal is:

0 : Disabled.

1 : Enabled.

Setting this parameter enables override by the feedrate override signal

<G012> to be applied for rigid tapping operation (cutting and extraction)

in rigid tapping.

The spindle speed override is fixed to 100%, but override is also applied to

the spindle speed in synchronization with the feedrate along the tapping

axis by feedrate override.

The override cancel signal OVC <bit 4 of G006> also become available.

NOTE

1 When this parameter is set to override the feedrate, override

by parameters (see parameters Nos. 5211 (T/M) and 5381

(M)) is disabled.

2 Regardless of whether this parameter is set, when feedrate

override is disabled by the override cancel signal OVC <bit

4 of G006>, override by parameters (see parameters Nos.

5211 (T/M) and 5381 (M)) is enabled.
