B–63833EN–1/02

15. PMC CONTROL FUNCTION

911

NOTE

This parameter is valid when TQF (bit 4 of parameter 1803)

is held 0.

2000

#6 #5 #4 #3 #2 #1

DGPRx

[Data type] Bit axis

DGPRx At power–ON, the torque constant (parameter No. 2105):

0 : Is automatically set to the standard value specific to the motor.

1 : Is not automatically set to the standard value specific to the motor.

NOTE

This parameter is intended to initialize the servo

parameters. It causes parameters other than those for

torque constants to be set automatically. Be careful when

using this parameter.

TRQx2007

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit axis

TRQx Torque control:

0 : Is not performed for the axis.

1 : Is performed for the axis.

2105 Torque constant

[Data type] Word axis

[Unit of data] 0.00001 Nm/(torque command)

[Valid data range] 1 to 32767

A torque constant is set for each motor torque characteristic.

NOTE

When a linear motor is used, the units of data are 0.001

N/(torque command).

3105

#6 #5 #4 #3 #2 #1

PCF

[Data type] Bit

PCF Movement along PMC–controlled axes is included in the actual speed

display

0 : Is included

1 : Is not included
