Series 0i/0i Mate - Model B Connection manual (Function) Page 665

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

11. PROGRAM COMMAND

647

NOTE

M series are not equipped with this parameter. Cutting

feedrates are specified by F commands in units of 0.001

mm/min for millimeter machines or 0.00001 inches/min for

inch machines.

#7 #6 #5 #4 #3 #2 #1 #0

3104 MCN

[Data type] Bit

MCN Machine position is:

0 : Not displayed according to the unit of input.

(Regardless of whether input is made in mm or inches, the machine

position is displayed in mm for millimeter machines, or in inches for

inch machines.)

1 : Displayed according to the unit of input.

(When input is made in mm, the machine position is displayed in mm,

and when input is made in inches, the machine position is displayed in

inches accordingly.)

#7 #6 #5 #4 #3 #2 #1 #0

3405 AUX

[Data type] Bit

AUX The least increment of the command of the second miscellaneous function

specified with a decimal point

0 : Assumed to be 0.001

1 : Depending on the input increment.

(For input in mm, 0.001 is assumed, or for input in inches, 0.0001 is

assumed.)

#7 #6 #5 #4 #3 #2 #1 #0

5006 OIM

[Data type] Bit

OIM When the unit is switched between the inch and metric systems, automatic

tool compensation value conversion is:

0 : Not performed

1 : Performed

NOTE

If you change this parameter, re–set the tool compensation

data.
