9. SPINDLE SPEED FUNCTION

519

#7 #6 #5 #4 #3 #2 #1 #0

3702 EMS

[Data type] Bit

EMS Multi–spindle control is

0 : Used

1 : Not used

#7 #6 #5 #4 #3 #2 #1 #0

3706

GTT

PG2

PG1

[Data type] Bit

PG2, PG1 Gear ration of spindle to first position coder

For the setting, see the description of parameter No.3707.

GTT Selection of a spindle gear selection method

0 : Type M.

1 : Type T.

NOTE

1 Type M:

The gear selection signal is not entered. In response to an

S command, the CNC selects a gear according to the speed

range of each gear specified beforehand in parameters.

Then the CNC reports the selection of a gear by outputting

the gear selection signal. The spindle speed corresponding

to the gear selected by the gear selection signal is output.

Type T:

The gear selection signal is entered. The spindle

speed corresponding to the gear selected by this signal is

output.

2 When the constant surface speed control is selected, type

T is selected, regardless of whether this parameter is

specified.

3 When type T spindle gear switching is selected, the

following parameters have no effect:

No. 3705#2 SGB, No. 3751, No. 3752, No. 3705#3 SGT,

No. 3761, No. 3762, No. 3705#6 SFA, No. 3735, No. 3736

However, parameter No. 3744 is valid.
