B–63833EN–1/02

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

305

The feed functions control the feedrate of the tool. The following two feed

functions are available:

1. Rapid traverse

When the positioning command (G00) is specified, the tool moves at

a rapid traverse rate set in the CNC (parameter No. 1420).

2. Cutting feed

The tool moves at a programmed cutting feedrate.

Override can be applied to a rapid traverse rate or cutting feedrate using

the override signal.

The positioning command (G00) positions the tool by rapid traverse.

G00 IP_ ;

G00 : G code (group 01) for positioning (rapid traverse)

IP_ ; Dimension word for the end point

In rapid traverse, the next block is executed after the specified rate

becomes 0 and the servo motor reaches a certain range set by the

parameter (No.1826) (in–position check).

A rapid traverse rate is set for each axis by parameter No. 1420, so no rapid

traverse rate need be programmed.

The following overrides can be applied to a rapid traverse rate with the

rapid traverse override signal:F0, 25, 50, 100%

F0: Allows a fixed feedrate to be set for each axis by parameter No. 1421.

In addition, the use of the 1% rapid traverse override selection signal

allows a rapid traverse override of between 0% and 100% to be applied

in 1% steps.

[Function] This signal indicates that a move command is executed at rapid traverse.

[Output condition] “1” indicates that an axis starts moving after rapid traverse has been

selected.

“0” indicates that an axis starts moving after a feedrate other than rapid

traverse has been selected. This holds true for both automatic and manual

operation modes.

7.1

FEEDRATE

CONTROL

7.1.1

Rapid Traverse Rate

General

Signal

Rapid traversing signal

RPDO <F002#1>
