12. DISPLAY/SET/EDIT

B–63833EN–1/02

750

Parameter setting enables one external operator message (consisting of up

255 characters) or, simultaneously, up to 4 external operator message

(consisting of up to 63 characters) to be displayed.

External operator messages can be logged in a history file.

These messages can be displayed on the external operator message history

screen.

#7 #6 #5 #4 #3 #2 #1 #0

3112 OMH

[Data type] Bit

OMH The external operator message history screen is:

0 : Not displayed.

1 : Displayed.

#7 #6 #5 #4 #3 #2 #1 #0

MS13113 MS0 MHC

MHC External operator message history data:

0 : Cannot be cleared.

1 : Can be cleared.

(Such data can be cleared using the [CLEAR] soft key.)

MS0, MS1 Set the number of items and the item length.

MS1 MS0 Number of history

data characters

Number of history

data items

0 0 255 8

0 1 200 10

1 0 100 18

1 1 50 32

CAUTION

When the values of MS0 and MS1 are changed, all

preserved external operator message history data is

cleared.

12.1.17

External Operator

Message Logging and

Display

General

Parameter
