Series 0i/0i Mate - Model B Connection manual (Function) Page 407

Connection manual (Function)

Page of 1090

/ 1090

B–63833EN–1/02

7. FEEDRATE CONTROL/ACCELERATION

AND DECELERATION CONTROL

389

NOTE

When parameter No. 1621 (time constant T2 used for

bell–shaped acceleration/deceleration in rapid traverse) is

set to 0, linear acceleration/deceleration is applied in rapid

traverse even. In this case, this parameter stands for a time

constant used for linear acceleration/ deceleration in rapid

traverse.

1621

Time constant t T2 used for bell–shaped acceleration/deceleration

in rapid traverse for each axis

[Data type] Word axis

[Unit of data] ms

[Valid data range] 0 to 512

Specify time constant T2 used for bell–shaped acceleration/deceleration

in rapid traverse for each axis.

NOTE

1 Set parameter No. 1620 to time constant T1 used for

bell–shaped acceleration/deceleration in rapid traverse,

and set this parameter to time constant T2.

For details of time constants T1 and T2, see the general

description in this section.

2 When this parameter is set to 0, linear acceleration/

deceleration is applied in rapid traverse. The setting in

parameter No. 1620 is used as a time constant in linear

acceleration/deceleration.

CONNECTION MANUAL

(This manual)

7.2.1 Automatic Acceleration/Deceleration

Reference item
