13.TOOL DATA BASE FUNCTION OPERATION B-63874EN/05
- 258 -
13.4 SETTING OF TOOL GRAPHIC DATA
Several items are needed to execute machine simulation in addition to
items that explained up to here. These items are called Graphic Data.
Graphic Data is showed below.
13.4.1 Tool Graphic Data
Tool graphic data are defined by parameters, from No.27350 to
No.27383. When these parameters aren’t defined, appropriate value
will be inserted automatically. For details, refer to the description of
“Parameter” in APPENDIX.
Tool graphic data for turning tools
Kind of tool General Threading Grooving
Data 1 Tip position Tip position Tip position
Data 2 Tip length Tip width Holder length
Data 3 Holder length Holder length Holder width
Data 4 Holder width Holder width
Data 5 Holder length 2
Data 6 Holder width 2
Kind of tool Button turning Straight
Data 1 Tip position Tip position
Data 2 Holder length Tip length
Data 3 Holder width Holder length
Data 4 Holder width
Data 5 Holder length2
Data 6 Holder width 2
Tool graphic data for milling tools
Kind of tool Drill Chamfer Flat endmill Ball endmill
Data 1 Tip length Tip length Tip length Tip length
Data 2 Cutter length
Data 3 Shank length
Data 4 Shank diameter
Kind of tool Tap Reamer Boring Face mill
Data 1 Tip length Tip length Tip length Tip length
