1.MILLING CYCLE MACHINING TYPES B-63874EN/05
- 476 -
1.11 C AXIS CLAMPING M CODE OUTPUT
1.11.1 Outline
C axis clamping and unclamping M codes are automatically output in
C axis cycles as followings, which position C axis in the cycle motion.
* C axis represents a rotating axis around Z axis in this
specifications.
(1) Hole machining cycles
In hole machining cycles combined with following figures, C
axis clamping and unclamping M codes are automatically output.
a) C-axis hole on the end face : G1572
b) C-axis hole on the end face (arbitrary) : G1573
c) C-axis hole on the cylindrical surface (arbitrary) : G1672
d) C-axis hole on the cylindrical surface (arbitrary) : G1673
(2) Grooving cycles
In grooving cycles combined with following figures, C axis
clamping and unclamping M codes are automatically output.
a) X-axis groove on the end face : G1571
b) Z-axis groove on the cylindrical surface : G1671
1.11.2 Value of M Code Output
M code set in following parameters are output
When zero is set, M code is not output.
(1) C axis clamping M code for main spindle : Parameter No.27005
(2) C axis unclamping M code for main spindle : Parameter No.27006
(3) C axis clamping M code for sub spindle : Parameter No.27011
(4) C axis unclamping M code for sub spindle : Parameter No.27012
