Manual Guide i Operators manual Page 5

Operators manual
B-63874EN/05 SAFETY PRECAUTIONS
s-3
1.2 GENERAL WARNINGS AND CAUTIONS
To ensure safety while using a machine featuring the MANUAL
GUIDE i function, observe the following precautions:
WARNING
1 Confirm, on the screen, that the data has been entered
correctly before proceeding to the next operation.
Attempting operation with incorrect data may cause the
tool to strike the workpiece or machine, possibly
breaking the tool or machine or injuring the operator.
2 Before starting the machine using the tool compensation
function, carefully determine the direction of
compensation and the compensation value, and ensure
that the tool will not strike the workpiece or machine.
Otherwise the tool or machine may be damaged or the
operator may be injured.
3 When using constant surface speed control, set the
maximum rotating speed of the spindle to a value that is
allowed for the workpiece and workpiece hold unit.
Otherwise, the workpiece or hold unit may be removed
by centrifugal force to damage the tool machine or injure
the operator.
4 Set all necessary parameters and data items before
starting MANUAL GUIDE i operations. Note that if the
cutting conditions are not suitable for the workpiece, the
tool may be damaged or the operator may be injured.
5 After creating a machining program using MANUAL
GUIDE i functions, do no run the machine on that
program immediately. Instead, confirm every step of the
resultant program, and make sure that the tool path and
machining operation are correct and that the tool will not
strike the workpiece or machine. Before starting
production machining, run the machine with no
workpiece attached to the machine to make sure that the
tool will not strike a workpiece or the machine. If the tool
strikes the machine and/or work-piece, the tool and/or
machine may be damaged, and even injuries the
operator.
CAUTION
After pressing the power-on button, do not touch any
keys on the keyboard until the initial screen appears.
Some keys are used for maintenance or special
operations such that pressing such a key may cause an
unexpected operation.
