Manual Guide i Operators manual Page 803

Operators manual

Page of 888

/ 888

B-63874EN/05 APPENDIX A.PARAMETERS

- 781 -

MM2 1 : The following menus are displayed.(It is effective only at MM0 = 1.)

• Hole Machining (G1000 to G1006) or (G1110 to G1114)

• Facing (G1020 to G1021)

• Contouring (G1030 to G1033)

• Pocketing (G1040 to G1043)

• Grooving (G1050 to G1053)

• XA-plane : Free figure (G1700 –> G1706)

• XA-plane : A-axis figure (G1770 –> G1773)

NOTE

1 When these parameter are all 0, the all milling

cycle menu except the menu of XA plame are

displayed on the screen

2 When the parameter No.27003 or No.27103 is set,

this parameter are initialize at the power ON and

pushing “F” key.

27005 CLMPM

CLMPM 0 : M code for Main spindle C-axis clamping is not output.

≠0 : M code for Main spindle C-axis clamping.

(Path-specific parameter)

Remark) refer to “III-1.10 C-axis Clamping M code Output”.

27006 UCLMPM

UCLMPM 0 : M code for Main spindle C-axis unclamping is not output.

≠0 : M code for Main spindle C-axis unclamping.

(Path-specific parameter)

Remark) refer to “III-1.10 C-axis Clamping M code Output”.

27007 CFCODM

CFCODM : Feedrate to replace all rapid traverse feedrate during C-axis machining

for feed per minute.

If 0 is set, the feedrate is assumed 2000 (mm/min) or 78.7 (inch/min) .

Unit of data:

For metric input (0000#2=0) : 1(mm/min)

For inch input (0000#2=1) : 0.01(inch/min)

NOTE

In XC plane, Polar coordinate interpolation is

used. That is, it is impossible to use G0 command.

Therefore, No.27007 is used instead of rapid

traverse.
