Servo Motor Beta Series Descriptions Page 129

Descriptions

Page of 337

/ 337

B-65232EN/03 FANUC AC SERVO MOTOR β series 2.SPECIFICATIONS AND CHARACTERISTICS

- 99 -

Model β

ββ

β1/3000

Specification : A06B-0031-Bxxx

0 1000 2000 3000

100

1 10 100 1000

Over load duty characteristics

"ON" time (sec.)

Duty (time %)

Speed - torque characteristics

Speed (min

-1

)

Continuous operating

Intermittent operating

Torque (Nm)

110%

120%

130%

140%

150%

170%

210%

Data sheet

Parameter Symbol Value Unit

Rating rotation speed Nmax 3000 min

-1

Rated torque at stall (*) Ts

kgfcm

Rotor inertia Jm

0.00033

0.0034

kgm

kgfcms

Continuous RMS current at stall (*) Is 3.2 A(rms)

Torque constant (*) Kt

0.31

3.2

Nm/A(rms)

kgfcm/A(rms)

Back EMF constant (1-phase) (*)

10.9

0.10

V(rms)/1000min

-1

V(rms)sec/rad

Armature resistance (1-phase) (*) Ra 0.96 Ω

Mechanical time constant tm 0.0011 s

Thermal time constant tt 15 min

Static friction Tf

0.1

kgfcm

Mass 2.5 kg

(*)The values are the standard values at 20°C and the tolerance is ±10%.

The speed-torque characteristics very depending on the type of software, parameter setting, and input

voltage of the digital servo motor. (The above figures show average values.)

These values may be changed without prior notice.
