B-65232EN/03 FANUC AC SERVO AMPLIFIER β series 5.POWER SUPPLY

- 163 -

5.1 INPUT POWER SUPPLY

5.1.1 Three-phase Input Power Supply for Motor Power

- Nominal rated voltage: 200 to 240 VAC

- Allowable voltage fluctuation: -15% to +10%

- Frequency: 50/60 Hz

- Allowable frequency fluctuation: ±2 Hz

- Power supply impedance: Voltage fluctuation cased by load (at

maximum output) not to exceed 7%

- Power supply unbalance: Within ±5% of the rated voltage

NOTE

The allowable voltage fluctuation is a change

observed for several minutes. It is not a continuous

change.

5.1.2 Single-phase Input Power Supply for Motor Power

In European countries, power sources are 380 to 415 VAC and

neutral-grounded. To use the β series amplifiers in these European

countries, it is necessary to install a power transformer at the input or

supply single-phase power.

To use the motors with single-phase power, observe the following:

(1) Power supply specification

- Nominal voltage rating: 220 to 240 VAC

- Allowable voltage fluctuation: -15% to +10%

- Frequency: 50/60 Hz

- Allowable frequency fluctuation: ±2 Hz

- Voltage fluctuation at acceleration/deceleration: 7% or less

NOTE

The allowable voltage fluctuation is a change

observed for several minutes. It is not a continuous

change.

5.1.3 Single-phase Input for Control Power

- Nominal rated voltage: 24VDC

- Allowable voltage fluctuation: ±10% (including momentary

variations)

- Power supply ratings

Power supply rating per amplifier

FSSB interface 0.6A

I/O Link interface 0.9A

PWM interface 0.4A
