9.CONNECTORS DESCRIPTIONS FOR FANUC AC SERVO MOTOR β series B-65232EN/03
- 60 -
9.2.2 Specifications of β
ββ
βM0.2 and β
ββ
βM0.3 Connectors for Signal
The specifications of the signal connector (cable side) for βM0.2 and
βM0.3 are indicated below.
The connector is not drip-proof.
For signal
Housing
specification
(tyco Electronics
AMP)
1-1318118-6
(D-2100D Receptacle housing 12 poles)
Contact
specification
(tyco Electronics
AMP)
1318107-1
(D-2 Receptacle contact M)
1318108-1
(D-2 Receptacle
contact S)
Applicable
wire size
0.18 to 0.5 mm
2
0.3 to 0.85 mm
2
0.08 to 0.2 mm
2
Wire insulator
outside
diameter
φ0.88 to 1.5 mm φ1.1 to 1.87 mm φ0.88 to 1.5 mm
Applicable
crimping tool
1463475-1
(Dedicated
crimping tool)
1276654-1
(D-2 M Standard
crimping tool))
1276653-1
(D-2 S Standard
crimping tool)
The connector kit for signal indicated below is available.
For signal
Connector kit
specification
(FANUC
specification)
A06B-6114-K241
Connector kit
components
Receptacle housing(1-1318118-6)×1
Receptacle contact D-2 M (1318107-1)×12
The table below indicates the tools dedicated to the connector.
Applicable contact
tyco Electronics
AMP specification
FANUC specification
For D-2 contact of M size
(Dedicated crimping tool
suitable for wire size from
0.18 to 0.5 mm
2
)
1463475-1 A06B-6114-K242
For D-2 contact of M size 1276654-1 A06B-6110-K220#D2M
Crimping
tool
For D-2 contact of S size 1276653-1 -
Pull-out
tool
For D-2 contact 1276716-1 A06B-6110-K220#D2R
