B-65232EN/03 FANUC AC SERVO AMPLIFIER β series 1.OVERVIEW

- 113 -

1 OVERVIEW

The main features of servo amplifier β series are as follows:

Features not dependent on the interface

(1) The servo amplifier β series is integrated with a power supply

unit, so that a compact system can be implemented for one or

two axes.

(2) The servo amplifier β series offers low-cost one-axis AC servo

amplifiers.

(3) The servo amplifier β series offers models that support not only

the FANUC standard interface, namely, the FSSB interface, but

also the I/O Link interface available with the CNC, Power Mate,

and PLC, and the conventional interface, namely, the PWM

interface (type B).

(4) The dimensions of each amplifier are the same even if a different

interface is employed.

(5) The servo amplifier β series offers a compact unit with its

amounting space and cubic volume reduced by about 50% when

compared with α SVU.

(6) The amplifier unit has been designed to conform to the European

VDE0160 safety standard, American UL standards, and

Canadian CSA standards.

The servo amplifier β series with the FSSB interface has the

following features:

(1) The servo amplifier β series with the FSSB interface offers one-

axis AC servo amplifiers that are designed for feed axes and are

used to drive the servo motor β series suitable for positioning

and the servo motor αi series suitable for use with feed axes.

The servo amplifier β series with the I/O Link interface has the

following features in addition to "Features not dependent on the

interface":

(1) Offer one-axis AC servo amplifiers suitable for use with

positioning axes, and used to drive the servo motor β series and

servo motor αi series.

(2) Have a position control function as well as a set to facilitate

control over peripheral devices such as turrets and ATCs.

(3) Can be connected to the Series 16/18/21/15i/16i/18i/20i/21i,

Power Mate, Power Mate i PMC, and PLC via the I/O Link,

thereby facilitating positioning axis expansion.

(4) Enable the master CNC to set and display parameters, the current

position, and diagnosis data.

(5) Support move commands that make movement synchronize with

a train of external pulses, thereby enabling diverse use.
