B-65232EN/03 FANUC AC SERVO AMPLIFIER β series 7.INSTALLATION CONDITIONS AND NOTES

- 171 -

7.3 NOISE PROTECTION

7.3.1 Separation of Signal Lines

If a power cable and signal cable run close to each other, noise can be

induced. So, ensure that a power cable is separated from a signal

cable. When a power cable and signal line cannot be separated from

each other for a reason, minimize the distance by which the two

cables run in parallel. When conduits are used, run a power cable

through one conduit, and run a signal cable through another conduit.

Cable type

Group Signal Action

Amplifier input power line

Motor power line

Magnetic contactor drive coil

(Note 3)

Separate these cables from those

of group B by bundling them

separately (Note 1) or by means of

electromagnetic shielding (Note 2).

Cable connecting the control

unit and servo amplifier

Sensor cable

Position coder cable

Separate these cables from those

of group A by bundling them

separately (Note 1) or by means of

electromagnetic shielding(Note 2).

In addition, shielding must be

provided.

NOTE

1 The bundle of group A cables must be separated

from the bundle of group B cables by at least 10

cm.

2 Electromagnetic shielding involves shielding

groups from each other by means of a grounded

metal (steel) plate.

3 Attach a noise suppressor such as a spark killer to

the magnetic contactor drive coil.
