Servo Motor Beta Series Descriptions Page 93

Descriptions

Page of 337

/ 337

B-65232EN/03 DESCRIPTIONS FOR FANUC AC SERVO MOTOR β series 9.CONNECTORS

- 63 -

9.3.2 Specifications of β

ββ

βM0.4 to β

ββ

βM1 Connectors for Signal

The specifications of the signal connector (cable side) for βM0.4 and

βM1 are indicated below.

The connector is drip-proof when fitted.

For signal

Straight

JN1DS10SL2 JN1DS10SL1

Connector body

specification

(Japan Aviation

Electronics Industry)

Elbow

JN1FS10SL2 JN1FS10SL1

Contact specification

(Japan Aviation Electronics

Industry)

JN1-22-22S

Applicable wire

size

AWG21 (0.5mm

, Strand structure

20/0.18)

AWG25 (0.18mm

, Strand structure

7/0.18)

Wire insulator

outside

diameter

φ1.5 mm or lower

Applicable

cable outside

diameter

φ6.5 to 8.0 mm φ5.7 to 7.3 mm

The connector kit for signals indicated below is available.

For signal

Straight

A06B-6114-K200#S

Connector kit

specification

(FANUC specification)

Elbow

A06B-6114-K200#E

Connector kit components

Connector body × 1

(Two types of bushing, one for φ6.5 to

8.0 and the other for φ5.7 to 7.3, are

included.)

Contact × 10

The table below indicates the tools dedicated to the connector.

Japan Aviation Electronics

Industry specification

FANUC specification

Crimping tool CT150-2-JN1-F A06B-6114-K201#JN1L

Pull-out tool ET-JN1 A06B-6114-K201#JN1R

NOTE

The contacts of the connectors are so structured

that the wire and insulator are crimped together.

So, be sure to observe the specified insulator

diameter. Other types of wires may be usable,

depending on wire and tool. For details, consult

with the connector manufacturer.
